  • [중고][EV200AAANA] TE KILOVAC 파워릴레이 E-Mech Contactor DC(Coil) 12-24V 500A - 차량용, 대전력용
    [중고][EV200
    50,000

리뷰 0 위시 18

[중고][EV200AAANA] TE KILOVAC 파워릴레이 E-Mech Contactor DC(Coil) 12-24V 500A - 차량용, 대전력용 요약정보 및 구매

상품 선택옵션 0 개, 추가옵션 0 개

제조사 TE Connectivity
원산지 멕시코
브랜드 TE
모델 ev20aaana
시중가격 160,000원
판매가격 50,000원
포인트 0점
최대구매수량 2 개

선택된 옵션

  • 수량
    +0원
위시리스트

관련상품

등록된 상품이 없습니다.

상품 정보

상품 상세설명


[EV200AAANA] 파워릴레이 E-Mech Contactor DC(Coil) 12-24V 500A - 차량용, 대전력용



차량용 및 대전력 DC 제어용 릴레이 입니다.



장비에서 분리한  제품입니다.



•Designed to be smallest, lightest weight, lowest cost sealed contactor in the industry

with current rating 500A carry , 2000A interrupt at 320V


•Built-in coil economizer - only 1.7W hold power at 12V DC and it limits back EMF to 0 V.


•Operate at 9V min. - 36V


•Normal open


•Hermetically sealed - intrinsically safe, operates in explosive/harsh environmental with on oxidation or contamination of coils or contacts, including longperiods of non-operation.


•CE marketed for EV application


•Weight: 0.95lb (430g)



•AIAG GS9000 designed, built and approved.





Relay TypePower Contact Current Max500A
Contact ConfigurationSPST N/O Coil TypeDC Coil
Coil Current3.8A Relay MountingPanel
External Length / Height55.81mm External Width80.48mm
Contact Current DC Max250A Mounting TypePanel
No. of Poles1 Operating Temperature Max85°C
SeriesG9EC Temperature Operating Min-40°C
Approval BodiesCE Marked Approval CategoryUL Recognised
Coil Voltage Max36V DC Coil Voltage Min9V DC
Contact Style1 form A Current Limit Max500A
Current Rating200A Dielectric Strength VDC2200V AC
Fixing Centres68.28mm Insulation Resistance100Mohm
Must Actuate Voltage9V Must Release Voltage6V
Operating Time15ms Release Time12ms
Weight425g
